Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line

Name: Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line
Brand: DAWSON
Price: 23 USD

Best Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line wholesale

Brand Name : DAWSON

Model Number : PET170S/530

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : USD 23,500 ~ 25500 / set

Payment Terms : L/C, T/T

Supply Ability : 200 sets / month

Delivery Time : 5-8 weeks

Packaging Details : Standard Export Packing

Clamping force : 1700 KN

Injection weight : 527g (PET)

Space between tie bar : 460*460mm

Mould thickness : 180~500mm

Platen stroke : 435mm

Warranty : 12 month

Style : Horizontal

Screw diameter : 50mm

Plasticizing capacity : 196 g/s

Preform neck : 20~120mm

Output : 2000~2800 pcs/h

Language : English or other specified

Cavity : 4, 8, 12

Contact Now

Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line

DAWSON MACHINERY & MOULD GROUP

Injection Molding Machine

Specialized for making PET preforms, small neck as well as wide neck.
PET material special screw, all machine adopt latest Taiwan control system,
World class famous brand components such as Japan YUKEN hydraulic valve for highest quality standard and machine performance.
We also able to provide mould design and manufacture to help you build up your own manufacturing.

Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line

Technical Parameters

Parameters		PET170S/530	PET230S/1000	PET270S/1000	PET270S/1500
Screw diameter	mm	50	62	62	70
Theoretical shot volume	cm3	450	860	860	1300
Shot weight	g	527	1006	1006	1521
Clamping force	KN	1700	2300	2700	2700
Toggle stroke	mm	435	475	540	540
Ejector stroke	mm	135	140	150	150
Space between tie bars	mm	460 * 460	520 * 520	570 * 570	570 * 570
Mould thickness	mm	180 ~ 500	200 ~ 530	200 ~ 550	200 ~ 550
Motor power	kw	28	36	43	56
Machine size	m	5.5 * 1.4 * 2.1	6.14 * 1.5 * 2.14	6.34 * 1.6 * 2.25	7.21 * 1.7 * 2.37
Machine weight	ton	6.5	7.5	8.5	9

Details Images Wide Neck PET Plastic Injection Mould Machine Jar Cup Can Container Preform Production Line

DAWSON MACHINERY & MOULD GROUP

Starting Business since 2003!

Our injection molding machines are sold to all over the world, to many South America, Asia, Africa countries.

Local service team in Saudi Arabia, Colombia, Panama, South Africa ...

Located in Zhangjiagang city, we are experienced in injection molding machine project. Help a lot of customers build their own business and production line.

Professional aftersale team solve your problems during production.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
